7775 Henry Purge Valve 1/2" MPT x 1/2" FPT Angle
List Price
$125.52
List Price
$125.52
Web Price
$110.49
Details
Henry 7775 Packed Shut-off Valve with 1/2" MPT bottom x 1/2" FPT side connections. Maximum working pressure 1000 psig (6900 kPa).
Packed valves are so called as the stem is sealed via a packed gland.
Applications
Henry Technologies packed valves are used in a variety of air conditioning and refrigeration applications for isolating, flow control, charging and purging purposes.
All valves are suitable for HCFC and HFC refrigerants, along with their associated oils.
The 7761 to 7775 models are also suitable for ammonia.
Materials of Construction
The valve body is made from steel. The stem is made from plated steel. A metal-to-metal seat seal is used. A graphite compound is used for the packing gland. The seal cap is made from moulded plastic or steel.
Dimensions
| A Dim. | B Dim. | C Dim. | D Dim. | Ø E Dim. |
| 109 mm | 38 mm | 44 mm | N/A | 12 mm |
More Information
| Weight | 2.000000 |
|---|---|
| Condition | New |
| Brand | Henry |
| Body | Forged Steel |
| Maximum Pressure (psig) | 1000 psig (6900 kPa) |
| Width | 2.7 |
| Height | 1.1 |
| Length | 4.7 |
| Depth | 0.0000 |
